Up to 24 Concurrent WebAssembly Instances on an ESP32-S3 Running Zephyr

How many concurrent WebAssembly instances can you run on a $4 microcontroller? We tested it on an ESP32-S3 running Zephyr RTOS, using WAMR’s classic interpreter and three hand-crafted WAT workloads. The answer: 24 CPU-bound instances and 2 stateful instances — all isolated, zero errors, no operating system in sight.

Hardware

The test board is an ESP32-S3-WROOM-1 — a dual-core Xtensa LX7 at 240 MHz with 512 KB of internal SRAM and no external RAM. At roughly $4 in quantity, it sits at the low end of what embedded teams reach for when they need processing headroom on a budget.

Attribute	Value
SoC	ESP32-S3
CPU	2 × Xtensa LX7 @ 240 MHz
Internal SRAM	512 KB
Flash	8 MB (WROOM-1 module)
External RAM	None
Price	~$4
RTOS	Zephyr 4.3.99
WASM Runtime	WAMR classic interpreter
Active cores	1 (`esp32s3_devkitc/esp32s3/procpu`)

The Zephyr target esp32s3_devkitc/esp32s3/procpu pins execution to Core 0. Core 1 is not used. This is a deliberate choice: Zephyr’s Xtensa SMP support on ESP32-S3 was still maturing at the time of this test, and single-core removes any SMP scheduling variables from the results. Everything measured here comes from 240 MHz of a single Xtensa LX7.

WAMR on Zephyr

WAMR (WebAssembly Micro Runtime) is the Bytecode Alliance’s embedded WASM interpreter, designed to run on devices where Linux and a full runtime like Wasmtime are not an option. It ships multiple execution tiers — AOT, fast interpreter, classic interpreter — and a platform abstraction layer (PAL) that handles threading, memory, and time across different RTOS environments.

Zephyr’s WAMR integration defaults to the classic interpreter (WASM_ENABLE_FAST_INTERP=0). The classic interpreter evaluates WASM opcodes directly from the bytecode buffer without modifying it. This is a safer default on Zephyr: the RTOS can mark memory regions non-writable, and any runtime that modifies its own bytecode buffer would fault. The classic interpreter leaves the buffer untouched, which also allows WASM bytes to be stored in read-only flash regions and copied to RAM only when needed.

Shared-Module Architecture

The key to running many concurrent instances on constrained hardware is WAMR’s shared-module architecture. Instead of loading a separate copy of the WASM module for each task, you parse the bytecode once and instantiate it many times.

Shared module architecture diagram Figure 1. WAMR shared-module architecture: wasm_runtime_load() parses bytecode once into an immutable wasm_module_t; each wasm_runtime_instantiate() creates an isolated instance with its own linear memory and interpreter stack.

The API maps directly:

// Parse once — produces an immutable wasm_module_t
wasm_module_t module = wasm_runtime_load(wasm_bytes, wasm_size, err, sizeof(err));

// Instantiate N times — each gets isolated linear memory + stack
for (int i = 0; i < n; i++) {
    inst[i] = wasm_runtime_instantiate(module, stack_kb * 1024, heap_kb * 1024, err, sizeof(err));
    env[i]  = wasm_runtime_create_exec_env(inst[i], stack_kb * 1024);
}

The parsed wasm_module_t is shared and immutable. Each wasm_module_inst_t carries its own linear memory (for workloads that declare (memory ...)), its own interpreter stack, and its own execution environment. Instances cannot observe each other’s memory.

Instance Lifecycle

Every instance follows the same lifecycle from load to teardown:

WASM instance lifecycle diagram Figure 2. WASM instance lifecycle: load → instantiate → execute → destroy → unload. Multiple instances share the single wasm_module_t produced by load; unload happens once, after all instances are destroyed.

Each Zephyr thread runs one instance to completion, then calls wasm_runtime_destroy_exec_env and wasm_runtime_deinstantiate. Once all threads have finished, wasm_runtime_unload releases the shared module. Post-teardown heap measurements confirm that WAMR leaves no allocations behind.

Benchmark Design

Three workloads, all hand-written in WAT (WebAssembly Text Format) and assembled with wat2wasm. WAT lets us control the binary exactly — no compiler passes, no runtime libraries, no hidden allocations. What you see in the source is what runs.

The .wat sources and a gen_headers.py script to regenerate the C header arrays live in examples/esp32s3-wasm-benchmark-zephyr/wat/. Requires wat2wasm from the WABT toolchain.

CPU Workload — FNV-1a Hash Loop

No linear memory. Pure computation: hash a 32-bit seed across 10 000 iterations of FNV-1a, accumulate into a global, repeat forever.

(module
  (global $acc (mut i32) (i32.const 2166136261))
  (func $fnv_iter (result i32)
    (local $i i32)
    (local $h i32)
    (local.set $h (global.get $acc))
    (block $break
      (loop $loop
        (br_if $break (i32.ge_u (local.get $i) (i32.const 10000)))
        (local.set $h
          (i32.mul
            (i32.xor (local.get $h) (local.get $i))
            (i32.const 16777619)))
        (local.set $i (i32.add (local.get $i) (i32.const 1)))
        (br $loop)))
    (global.set $acc (local.get $h))
    (local.get $h))
  (export "fnv_iter" (func $fnv_iter)))

Binary size: 90 bytes. Per-instance malloc cost: ~6 KB (4 KB WAMR interpreter stack + ~1–2 KB bookkeeping, no linear memory page).

MEM Workload — Linear Memory Write/Read

Declares one 64 KB linear memory page. Writes a byte pattern across 1 KB, reads it back 100 times per call, returns a checksum.

(module
  (memory 1 1)
  (func $mem_stress (result i32)
    (local $i i32) (local $sum i32)
    (block $outer_break
      (loop $outer
        (br_if $outer_break (i32.ge_u (local.get $i) (i32.const 100)))
        (local $j i32)
        (block $inner_break
          (loop $inner
            (br_if $inner_break (i32.ge_u (local.get $j) (i32.const 1024)))
            (i32.store8 (local.get $j)
              (i32.and (i32.add (local.get $i) (local.get $j)) (i32.const 255)))
            (local.set $j (i32.add (local.get $j) (i32.const 1)))
            (br $inner)))
        (local.set $j (i32.const 0))
        (block $read_break
          (loop $read
            (br_if $read_break (i32.ge_u (local.get $j) (i32.const 1024)))
            (local.set $sum
              (i32.add (local.get $sum)
                (i32.load8_u (local.get $j))))
            (local.set $j (i32.add (local.get $j) (i32.const 1)))
            (br $read)))
        (local.set $i (i32.add (local.get $i) (i32.const 1)))
        (br $outer)))
    (local.get $sum))
  (export "mem_stress" (func $mem_stress)))

Binary size: 145 bytes. Per-instance malloc cost: ~70 KB (64 KB WASM linear memory page + ~6 KB overhead).

MSG Workload — SPSC Ring Buffer

Declares one 64 KB linear memory page. Simulates a single-producer single-consumer ring buffer: writes 64 messages of 32 bytes each, reads them back, returns the count.

(module
  (memory 1 1)
  (global $head (mut i32) (i32.const 0))
  (global $tail (mut i32) (i32.const 0))
  (func $msg_stress (result i32)
    (local $count i32) (local $i i32) (local $slot i32)
    ;; produce 64 messages
    (block $prod_break
      (loop $prod
        (br_if $prod_break (i32.ge_u (local.get $i) (i32.const 64)))
        (local.set $slot
          (i32.mul (i32.rem_u (global.get $head) (i32.const 64)) (i32.const 32)))
        (i32.store (local.get $slot) (local.get $i))
        (global.set $head (i32.add (global.get $head) (i32.const 1)))
        (local.set $i (i32.add (local.get $i) (i32.const 1)))
        (br $prod)))
    ;; consume 64 messages
    (local.set $i (i32.const 0))
    (block $cons_break
      (loop $cons
        (br_if $cons_break (i32.ge_u (local.get $i) (i32.const 64)))
        (local.set $slot
          (i32.mul (i32.rem_u (global.get $tail) (i32.const 64)) (i32.const 32)))
        (drop (i32.load (local.get $slot)))
        (global.set $tail (i32.add (global.get $tail) (i32.const 1)))
        (local.set $count (i32.add (local.get $count) (i32.const 1)))
        (local.set $i (i32.add (local.get $i) (i32.const 1)))
        (br $cons)))
    (local.get $count))
  (export "msg_stress" (func $msg_stress)))

Binary size: 170 bytes. Per-instance malloc cost: ~70 KB (same as MEM — same (memory 1 1) declaration).

Memory Architecture

Understanding the results requires understanding where every byte lives on Zephyr.

DRAM Layout

The ESP32-S3’s 512 KB SRAM is divided between the Zephyr kernel, pre-allocated thread stacks, the malloc arena, and a small headroom margin.

Zephyr DRAM layout diagram Figure 3. Zephyr DRAM layout on ESP32-S3: thread stacks are pre-allocated in .noinit and never compete with the malloc arena used by WAMR.

Zephyr DRAM layout (399 KB usable dram0_0_seg):
  Zephyr kernel + BSS          ~100 KB  (code, globals, kernel data structures)
  Thread stacks (24 × 4 KB)     96 KB   (.noinit — never touches malloc arena)
  Malloc arena (WAMR)           192 KB  (CONFIG_COMMON_LIBC_MALLOC_ARENA_SIZE)
  Remaining headroom             ~11 KB

Thread stacks are declared with K_THREAD_STACK_ARRAY_DEFINE, which places them in the .noinit section. They are reserved at boot and never appear in the malloc arena accounting. WAMR calls malloc / free for module loads, instance allocations, and interpreter stacks. The two pools are completely separate: WAMR cannot accidentally exhaust thread stack memory, and creating a new thread cannot reduce the WAMR arena.

The trade-off is that the stack pool is fixed at boot. The benchmark pre-allocates 24 slots (96 KB). If the experiment needs more threads, the source constant must be changed and the firmware rebuilt.

Scheduling and Concurrency Limits

All threads run on Core 0. The Zephyr scheduler time-slices them cooperatively and preemptively. With 24 threads simultaneously active, the CPU is 100% utilised from the moment the second instance starts.

Zephyr scheduling and concurrency limits diagram Figure 4. Two independent ceilings bound concurrency: stack slots cap CPU-bound workloads at 24; the 192 KB malloc arena caps stateful workloads at 2.

Two independent ceilings determine the peak:

Stack-slot ceiling: 24 pre-allocated slots. CPU workloads hit this first because their per-instance arena cost is small (~6 KB × 24 = 144 KB, leaving 40 KB of arena still free when the run stops).
Arena ceiling: 192 KB. Stateful workloads (MEM, MSG) consume ~70 KB each; two instances leave 50 KB, which is not enough for a third (70 KB required).

Results

All three workloads run in the same firmware image under EXPERIMENT 0. Serial output captured at 115200 baud.

CPU Workload — 24 Concurrent Instances

=== WASM Stress Benchmark (Zephyr) ===
workload=cpu  wasm_stack=4KB
thread_stack=4KB (pre-allocated, 24 slots)  core=-1

instances=1    heap=185KB  min=185KB  cpu= 84%  up=3s
  +instance cost ~6KB  latency 0us
instances=2    heap=178KB  min=178KB  cpu=100%  up=5s
  +instance cost ~6KB  latency 0us
instances=4    heap=163KB  min=163KB  cpu=100%  up=10s
  +instance cost ~6KB  latency 0us
instances=8    heap=137KB  min=137KB  cpu=100%  up=19s
  +instance cost ~6KB  latency 0us
instances=16   heap= 91KB  min= 91KB  cpu=100%  up=38s
  +instance cost ~6KB  latency 0us
instances=24   heap= 40KB  min= 40KB  cpu=100%  up=56s
  +instance cost ~6KB  latency 0us

--- Peak: 24 concurrent WASM instances ---

  id  task   iters  errors  latency_us
   0  cpu      311       0           0
   1  cpu      239       0           0
   2  cpu      201       0           0
  ...
  23  cpu        6       0           0
---

Post-teardown heap: 191KB free

Each CPU instance costs ~6 KB from the malloc arena: 4 KB WAMR interpreter stack plus ~1–2 KB of runtime bookkeeping. No linear memory page is allocated because the CPU workload declares none.

The run stopped at 24 because all pre-allocated stack slots were consumed — not because memory ran out. At peak, 40 KB of arena remained free. Post-teardown, the full 191 KB returns: WAMR is clean.

The latency 0us values are a known measurement gap: k_cycle_get_64() on this Zephyr/ESP32-S3 target does not advance at the expected rate and produces zero-width elapsed times. Actual per-call duration can be read from iteration counts: instance 0 ran from t ≈ 3 s to t ≈ 56 s (53 seconds total) and completed 311 iterations — approximately 170 ms per call at 24-instance load on a single 240 MHz core.

CPU utilisation hits 100% at 2 instances. With 24 threads all running WASM on one core, the scheduler is fully saturated, which is expected and correct.

MEM Workload — 2 Concurrent Instances

=== WASM Stress Benchmark (Zephyr) ===
workload=mem  wasm_stack=4KB
thread_stack=4KB (pre-allocated, 24 slots)  core=-1

instances=1   heap=120KB  min=40KB  cpu=98%  up=62s
  +instance cost ~70KB  latency 0us
instances=2   heap= 50KB  min=40KB  cpu=100% up=65s
  +instance cost ~70KB  latency 0us
[wrn] bench: [2] instantiate failed: allocate linear memory failed
instances=3   TASK_DIED (errors=1)

--- Peak: 2 concurrent WASM instances ---
Post-teardown heap: 191KB free

Each MEM instance consumes ~70 KB from the 192 KB arena: 64 KB for the WASM linear memory page declared by (memory 1 1), plus ~6 KB of overhead. Two instances occupy 140 KB, leaving 50 KB. A third instance requires 70 KB — the arena cannot provide it.

The error is clean: wasm_runtime_instantiate returns false, the thread reports the failure and exits. No memory is leaked; the two surviving instances continue running without error.

MSG Workload — 2 Concurrent Instances

=== WASM Stress Benchmark (Zephyr) ===
workload=msg  wasm_stack=4KB
thread_stack=4KB (pre-allocated, 24 slots)  core=-1

instances=1   heap=120KB  min=40KB  cpu=68%  up=72s
  +instance cost ~70KB  latency 0us
instances=2   heap= 50KB  min=40KB  cpu=100% up=74s
  +instance cost ~70KB  latency 0us
[wrn] bench: [2] instantiate failed: allocate linear memory failed
instances=3   TASK_DIED (errors=1)

--- Peak: 2 concurrent WASM instances ---
Post-teardown heap: 191KB free

Identical pattern to MEM. The MSG workload also declares (memory 1 1), so the per-instance cost is the same 70 KB. At 2 instances, 50 KB remains and both run cleanly at 100% single-core utilisation with zero errors.

Summary

Workload	Peak instances	Per-instance arena cost	Limiting factor
CPU (no linear mem)	24	~6 KB	Stack-slot pool (24 pre-allocated)
MEM (64 KB linear mem)	2	~70 KB	192 KB malloc arena
MSG (64 KB linear mem)	2	~70 KB	192 KB malloc arena

Arena consumption across all three experiments:

Arena consumption chart Figure 5. Malloc arena consumption as instance count grows for each workload. CPU workloads spend ~6 KB per instance; MEM/MSG spend ~70 KB. The 192 KB ceiling terminates MEM/MSG at 2 instances; CPU hits the stack-slot ceiling first at 24, with 40 KB of arena still available.

What This Means for Propeller

Propeller is an open-source orchestration system for WebAssembly workloads on embedded devices. A manager node compiles tasks to WASM and dispatches them over MQTT to a fleet of proplets — worker nodes that load and run the binaries. A single proplet might serve tasks from several independent deployments simultaneously.

Propeller edge dispatch diagram Figure 6. Propeller dispatch model: the manager sends compiled WASM binaries over MQTT; each proplet loads the binary via WAMR and runs it in an isolated instance. Multiple concurrent instances run within the same proplet process.

This benchmark answers the capacity question for the Zephyr proplet configuration:

24 concurrent stateless functions per device with the default configuration. The 24-slot stack pool is a single constant in source; rebuilding with 30 slots gives ~29–30 instances (the arena would run out before the stack pool at ~29 instances, where 6 KB × 29 ≈ 174 KB leaves only ~18 KB — enough for ~3 more instances before OOM).
2 concurrent stateful functions per device with the default 192 KB arena. If your pipeline stages maintain local state (ring buffers, accumulators, running statistics), budget 70 KB per concurrent instance. The ESP32-S3R8 variant (8 MB PSRAM) lifts this ceiling substantially.
Isolation is guaranteed by construction: WAMR instances cannot access each other’s linear memory. Across every experiment — 24 CPU instances, 2 MEM instances, 2 MSG instances — zero cross-contamination errors were observed. Propeller’s per-function isolation guarantee holds at the microcontroller level.
Zephyr’s vendor-neutral HAL is compatible: the WAMR runtime, the WASM binaries, and the shared-module architecture work unchanged on Zephyr. Teams that need to target an nRF5340, an STM32L5, and an ESP32-S3 from the same codebase can deploy Propeller proplets across all three without re-benchmarking.

Conclusion

A $4 ESP32-S3 running Zephyr RTOS can sustain 24 concurrent WebAssembly instances for CPU-bound workloads and 2 concurrent instances for workloads with 64 KB linear memory — all isolated, all zero-error, on a single 240 MHz core with no external RAM.

The limits are deterministic and configurable:

The CPU ceiling is a stack-slot count, not an OOM. Pre-allocate more stack slots at compile time and the arena absorbs more instances — the 192 KB arena still had 40 KB free when the 24-slot pool was exhausted.
The MEM/MSG ceiling is a Kconfig parameter. CONFIG_COMMON_LIBC_MALLOC_ARENA_SIZE is one line; increasing it (and the headroom permits a small increase) directly lifts stateful instance capacity.

WAMR’s shared-module architecture is what makes this possible: parsing happens once, and each wasm_runtime_instantiate() costs only the per-instance overhead — not a full copy of the module. On Zephyr, thread stacks are segregated into the .noinit section and never compete with the WAMR malloc arena, which keeps the accounting clean and the limits predictable.

The benchmark source is at examples/esp32s3-wasm-benchmark-zephyr. Propeller is open source at github.com/absmach/propeller.

Measurements: ESP32-S3-WROOM-1, Zephyr 4.3.99, WAMR classic interpreter, single core (esp32s3_devkitc/esp32s3/procpu). Timing via k_cycle_get_64() — latency values unreliable on this target; iteration counts used for duration estimates. All experiments run in-process with no external tooling.
